1.2312 tool steel is ideally suited for the production of moulds where improved machinability is required.  Typical applications include die holders, zinc die casting dies, backers, bolsters and injection moulds. The versatility of this plastic mould tool steel with its high tensile characteristics enables uses for a variety of other applications such as shafts and wear strips

Heat slowly, allowing sufficient time for the steel to become heated through. Begin forging at 1050°C. Do not forge below 930°C reheating if necessary. After forging, cool very slowly.

When dies are heavily machined, we recommend stabilising just before finish machining in order to relieve machining strains. Heat to 460-500°C. Soak well and allow to cool in the air.

Heat uniformly to 710-740°C.  Soak well, cool slowly in the furnace.

Heat uniformly to 830-870°C until heated through. Quench in oil.

Heat uniformly and soak at the tempering temperature for at least one hour per 25mm of section. Allow to cool in still air.

Tools machined from pre-hardened 1.2312 may be nitrided to give a wear resistant case of approximately Rockwell C60 surface hardness with a case depth of .35mm to 0.5mm. Nitriding also increases the corrosion resistance. After nitriding at 525°C in ammonia gas the surface hardness of the tool will be approximately 650HV.

Tools produced from 1.2312 tool steel may be case hardened, which can achieve a surface hardness of between 55 to 59 Rockwell C.

Induction or flame hardening of will achieve a hardness of 50 to 55HRc. It is preferable to air cool, though smaller components may require forced cooling. Temper immediately after hardening.

Heat treatment temperatures, including rate of heating, cooling and soaking times will vary due to factors such as the shape and size of each steel component. Other considerations during the heat treatment process include the type of furnace, quenching medium and work piece transfer facilities. Please consult your heat treatment provider for full guidance on heat treatment of 1.2312 tool steel.

1.2312 tool steel is supplied in accordance with our ISO 9001 : 2008 registration.
